Customized FR4 HDI Printed Circuit Boards Multilayer For Home Appliance
Smart Home Pcb Hole Customized FR4 Smart Control Board For Home Appliance PCB Assembly Multilayer Layers HDI Cross Blind
Leadsintec has a professional technical team with 20 years of experience in PCB manufacturing,constantly enhance the level of PCB technology and production capacity. As a PCB supplier, Leadsintec is not only offering one-stop service as PCB production, and PCB Assembly, but also taking great advantages on prompt delivery time and competitive price with no quality compromise.
Our main service:
1. PCB manufacturing from 1 to 48 layers;
2. Component sourcing;
3. PCB Assembly;
4. Write program for customers;
5. PCB/ PCBA Test.
We understand that bringing a product to market in a timely and cost effective manner can mean everything in business. Our quality, experience, service and pricing combine to become your efficient and reliable electronic supplier.
Leadsintec has been selected as the “excellent partner of the year” by numerous well-known enterprises, and won many domestic and authorized certifications at home and abroad, such as Chinese high-tech project certification, ISO9001, ISO14001, ISO13485, IATF16949 quality management system standard and customized CE, UL, FCC and other product certifications according to the customer's requirements.
PCB Manufacturing Capability:
As a 20 years PCB manufacturer in China, Leadsintec is providing the latest printed circuit board technologies and highest quality standards for electronics industry. You can trust us to meet your demands, from small volume to mass production whatever the simplest PCB boards or the most complex.
| Article | Description | Capability |
| Laminate Materials | FR4, high TG FR4, high frequency, alum, FPC |
| Board Cutting | Number of layers | 1-48 |
Min.thickness for inner layers
(Cu thickness are excluded) | 0.003”(0.07mm) |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” |
| 4layer:0.01±0.008” |
| 8layer:0.01±0.008” |
| Bow and twist | no more than 7/1000 |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) |
| PTH hole tolerance | ±0.002″(0.005mm) |
| NPTH hole tolerance | ±0.002″(0.005mm) |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) |
| Thickness | (0.012*0.017mm) |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) |
| Component Sourcing | Yes |
| Tolerance of PCB | ±5% |
| Max Size of Finish Board | 700*460mm |
| MOQ | NO MOQ (1pcs) |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… |
| PCB Outline | Square,circle,irregular(with jigs) |
| Package | QFN,BGA,SSOP,PLCC,LGA |
| Sub-assembly | Plastic,metal,screen |
| Min Line/Space | 0.075/0.075mm |
Flexible Volume Assembly Alternatives:
Leadsintec is China PCB assembly manufacturer ,who offers complete PCB assembly services in Shenzhen , Leadsintec capable of providing turn-key and partial turn-key printed circuit board assembly services.
For full turn-key, we take care of the entire process, including manufacturing of Printed Circuit Boards, procurement of components (100% original) , PCBA Testing , continuous monitoring of quality and final assembly.
* Prototype PCB Assembly
* Low-Volume, High Mix PCB Assembly
* High-Volume PCB Assembly
* Consigned & Partial PCB Assembly
* Full Turnkey PCB Assembly
* Cable & Wire Harness Assembly
* Box Build Assembly Services
Manufacturing Machine Show
SCHMOLL and V-cut machine from German, POSALUX from Switzerland, laminated yarn from Italy, the AOI of brand Camtek from Israel, the Developing line and advanced test machine CMI900 from Japan, etc.
Major Testing Equipment
AOI, Flying probe tester, Tester, Impedance tester, Tensile tester, ROHS tester, coordinate measuring machine, Thermal shock chamber, all just for to make the high quality!
FAQ:
Q: What service do you have?
Leadsintec : We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal,final assembly, testing and other value-added service.
Q: What is needed for PCB & PCBA quotation?
Leadsintec : For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
For PCBA: PCB information, BOM,Testing documents.
Q: How to keep our product information and design file secret ?
Leadsintec : We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
Q: What are the main products of your PCB/PCBA services?
Leadsintec : Automotive, Medical, Industry Control, IOT, Smart Home, Military, Aerospace.
Q: What is your minimum order quantity (MOQ)?
Leadsintec : Our MOQ is 1 PCS, sample and mass production all can support.
